Nickel Alloy 625 Union ASME B16.11
INCONEL 625 Forged Union
High quality ASME B16.11 Nickel alloy 625 Union is supplied in socket weld and threaded types, dimensions is within 4 inch.
Nickel alloy 625 is also known as Inconel 625, UNS 6625, it is a corrosion resistant material certified to the NACE standard. inconel 625 forged unions resistant to many corrosion such as acid corrosion, oxidation and reducing environment.
Zizi is qualified manufacturer of nickel alloy forged fittings, those 1/2” Inconel 625 unions is supplied with MTC.
Socket Weld Union & Threaded Union Dimensions
Forged Union Dimensions
Nickel Alloy 625 Union Weight
INCONEL 625 Forged Union Weight Chart
Forged Fittings Specification
| Standard | ASME B16.11, SH3410, JIS B2316, BS3799 INCONEL 625 Forged Union |
|---|---|
| Size | 1/8″, 1/4″, 3/8″, 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 2 1/2″, 3″, 4″ |
| Pressure | 3000LB, 6000LB, 9000LB |
| Types | Socket Weld and Threaded Fittings |
| Product | Nickel Alloy 625 Union, Coupling, Olet, Elbow, Tee, Cap, Nipple, Plug, Bushing |
| Stainless Steel Union | ASTM A182 F304, F304L, F306, F316L, F304H, F309S, F309H, F310S, F310H, F316TI, F316H, F316LN, F317, F317L, F321, F321H, F11, F22, F91, F347, F347H, F454L, ASTM A312/A403 TP304, TP304L, TP316, TP316L |
| Carbon Steel Union | ASTM/ ASME A 105, ASTM/ ASME A 350 LF 2, ASTM / ASME A 53 GR. A & B, ASTM A 106 GR. A, B & C. API 5L GR. B, API 5L X 42, X 46, X 52, X 60, X 65 & X 70. ASTM / ASME A 691 GR A, B & C |
| Nickel Alloy Union | ASTM / ASME SB 336, ASTM / ASME SB 564 / 160 / 163 / 472, UNS 2200 (NICKEL 200) , UNS 2201 (NICKEL 201 ) , UNS 4400 (MONEL 400 ) , UNS 8020 ( ALLOY 20 / 20 CB 3 ) , UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600 ) , UNS 6601 (INCONEL 601) , UNS 6625 (INCONEL 625) , UNS 10276 (HASTELLOY C 276) |
Features of Nickel Alloy 625 Forged Fittings
- Excellent resistance to aqueous and chloride corrosion
- High strength
- Outstanding weld-ability
- Withstand to stress corrosion cracking
- Resistance to high pressure and temperature
- Extensive application
Application
- Chemical Industry
- Gas and Oil
- Medicine
- Papermaking
- Seawater
Nickel Alloy 625 Properties
Chemical Composition, %
| Cr | Ni | Mo | C | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|
| 20-23 | 58-Balance | 8-10 | 0.1 Max | 0.5 Max | 0.5 Max | 0.015 Max | 0.015 Max | 5 Max |
Mechanical Properties
| Ultimate Tensile Strength | 0.2% Yield Strength | Elongation |
|---|---|---|
| 120 ksi | 60 ksi | 30% |
